Introduction to installation and test run of Instrument Cnc Machine with slant bed
June
20,
2022
In the actual cutting process, the inclined lathe has the function of selecting and matching power tools and 8-Position turret tool rest, so it can play an important role in the processing of different products, especially in complex and high-precision parts, which obviously have advantages that other products do not have. Now, Guangdong CNC lathe introduces the installation and test run of CNC lathe with inclined lathe bed.
1. When the NC lathe with inclined bed is placed on the foundation, it must be leveled in free state and locked by anchor bolts.
2. For ordinary lathes, the reading of the level gauge will not be higher than 0.04/1000mm, and for high-precision CNC lathes, the level gauge will not be higher than 0.02/1000mm. When measuring the installation accuracy, we often need to do it at a constant temperature. The measuring tool should be used after a period of constant temperature.
3. During the installation of NC lathe with inclined lathe bed, the installation method of forced deformation caused by NC lathe should be reduced as much as possible.
4. It is not allowed to dismantle some parts of the lathe casually when installing the inclined lathe bed. If some parts are dismantled, it is likely that the internal stress of the lathe will be distributed again, thus affecting the accuracy of the lathe.
Preparation before commissioning of NC lathe with inclined lathe bed
1. Before use, the CNC lathe with inclined lathe bed shall pass the geometric accuracy inspection, and then clean the whole machine. Specifically, the cotton cloth or silk cloth containing cleaning agent shall be used for cleaning. At this stage, cotton yarn or gauze shall not be used to avoid machine jamming. That is to say, the anti rust oil or anti rust paint applied by the NC lathe with inclined bed to protect the guide rail surface and processing surface when leaving the factory shall be cleaned, and t
Safety operation procedures and daily maintenance of Automatic CNC Machine
May
11,
2022
Safe operation technology
(1) Before work, they must wear labor protection products. Female workers must wear work hats and hair nets. They are not allowed to wear scarves and high-heeled shoes. During operation, they are not allowed to wear gloves, smoke, chat with others, concentrate, and play and make trouble in the workshop.
(2) Before spending the CNC Machine tool, you must check whether the lubrication and protective devices of all parts of the machine tool meet the requirements.
(3) Reasonably select cutting tools and fixtures. When clamping precision workpieces or thin and soft workpieces, the clamping method shall be appropriate and the force shall be appropriate to ensure that the clamping is firm and reliable. It is not allowed to knock hard. It can be knocked gently with a wooden hammer or cushion.
(4) During the operation, it is necessary to observe whether there are guns in the workpiece clamping at any time. If there are guns, it is necessary to turn the vehicle immediately to prevent hitting people. When observing the workpiece during the operation, the position should be appropriate.
(5) When the machine tool moves rapidly, pay attention to the surrounding conditions to prevent collision.
(6) In case of abnormal heating of the motor of the CNC lathe machine tool and abnormal sound, stop the machine immediately.
(7) The operation should be civilized. Do not put tools, measuring tools and workpieces on the abnormal track of the machine tool and the workbench at will. When the machine
